General Configuration#

Some information is specific to all web services, and we will discuss the parts of a web service here in more detail.

Adding A Webservice#

Each service requires an endpoint. The endpoint is determined by

  • Configured FQDN

  • Configured ScriptAlias

  • Web Service Name

A default endpoint for a webservice named Service would be:

For REST, we will create a routing later in the transport section.

For SOAP, the name of the Operation or Invoker will be the SOAP Action.

General Settings#

The general settings are:


The name of the webservice. This will be the endpoint.


A short description for the administrator about the purpose of the web service.

Remote system

Appeared to input the name of the remote system using the web service. Not required and not as part of the configuration.

Debug threshold

The level of debug information to be locked to the generic interface locking system.


The validity of the web service.

Type Of Webservice#

The software can act as a consumer (Invoker) or provider (Requester)

You must choose:

Network Transport


Error Handling Module

Choose an error handling module.


Choose the operation module for use by the consumer of the service.


Choose the invoker module used to consume a webservice.

Payload Options#

XSLT Force Array Tags#

There is a new config option “force array for tags” for the outgoind request data when using XSLT mappings. This option defines which XML elements will be converted to arrays when the data is converted to JSON. By default, this happens only when the same element occurs more than once on the same level. This is needed because some web services expect arrays in the request. Multiple element names can be used.

Without this setting:

  <label>my Label</label>


   "label": "my Label",
   "entry": [

With the value label for this setting the JSON will look like this:

   "label": [
      "my Label"
   "entry": [

A practical use for this can be found in the outgoing XSLT mapping of the MS Teams example.

System Configuration Data In Web Service Configuration#

Basic Requirment#

You will need to have a custom XML file to contain theese setting. You can extend this exapmle, by any amount of configuration items and maanage all your items centrally and comfortably from the system configuartion tool.

<?xml version="1.0" encoding="utf-8" ?>
<otrs_config version="2.0" init="Application">
    <Setting Name="GI_User1" Required="0" Valid="1">
            <Description Translatable="1">A user name to be used with the GI.</Description>
            <Item ValueType="String" ValueRegex="">User</Item>
    <Setting Name="GI_Route1" Required="0" Valid="1">
            <Description Translatable="1">A host name to be used with the GI.</Description>
            <Item ValueType="String" ValueRegex=""></Item>
    <Setting Name="GI_PW1" Required="0" Valid="1">
            <Description Translatable="1">A password to be used with the GI.</Description>
            <Item ValueType="String" ValueRegex="">secrect</Item>

You can also add varables directly to the Config.mapping

$Self->{'GI_User2'}      = 'secretuser';

Here are some exapmles for how to use these varables.

Tranport as BasicAuth (Example 1)#

Setting defined in the System Configuration can be used in the web service configuration. There are two ways to use them.

One possibility is to use the values in certain settings like the transport setting etc.

It is now possible to use smart tags of type CONFIG in the web service configuration. These tags contain values from system configurations. This allows it easier to handle passwords outside of the webservice configuration.

System Configuration configuration tag in web service configuration

BasicAuth in Mapping (Example 2)#

In addition to the network transport configuration, this is also possible directly in XSLT. It can also be used for user names and passwords, but also for default values such as queues, stats, etc.

<?xml version="1.0" encoding="UTF-8"?>
<xsl:transform version="1.0" xmlns:xsl="" xmlns:date="" extension-element-prefixes="date">
  <xsl:output method="xml" encoding="utf-8" indent="yes"/>
  <xsl:template match="RootElement">

FQDN in Routing (Example 3)#

System Configuration configuration tag in web service configuration

This feature is used with the Mattermost example to have the system configuration ProductName in the mapping available.


Keep often used settings like usernames, passwords, hostname, etc in the system configuration and share web service configurations between staging systems.

Why? E.g. to change credentials used in multiple web services by modifying a single setting.
